Chicken neck and breast skinning machine

Original legacy product photograph and watermark retained. Final configuration is subject to confirmation.

Further processing equipment / SR-66

Chicken neck and breast skinning machine

Rollers and a feeding mechanism remove skin from chicken necks and breasts. The brochure specifies 304 stainless steel, adjustments and guard-position interlocks, with a conveyor option for process integration.

Technical data awaiting factory confirmation

Model: SR-DX5600
Throughput: 3000 units/h / 件/小时（画册参考 / brochure reference）
Poultry type: 鸡、鸭及禽肉 / Chicken, duck and poultry cuts
Material: SUS304 / 画册标注 Brochure
Voltage: 按目的地和铭牌确认 / Confirm for destination & nameplate
Power: 3 kW（画册 / brochure）

Request a quote for this machine ↗

Technical specifications

Source: manufacturer 35-page product brochure, PDF page 21. Reference model: SR-DX5600 Brochure nominal output: 3000 units/h / 件/小时 Brochure power: 3 kW Dimensions (L × W × H, mm): 3500 × 1300 × 1700 The brochure lists guard and adjustment-position interlocks; validate the actual configuration at acceptance. Confirm throughput on a feed-item basis. Selection reference: final configuration, output and acceptance criteria are agreed for each project.
