Original legacy product photograph and watermark retained. Final configuration is subject to confirmation.

Conveying & auxiliary equipment / SR-77

Automatic weight grader

Automatic weighing and grading route carcasses or cuts into weight bands for portion control and downstream packing. Select the configuration for product dimensions, weight range and the required number of outlets.

Technical data awaiting factory confirmation

Model: SR-FJ800
Throughput: 3000 units/h / 件/小时（画册参考 / brochure reference）
Poultry type: 禽体、禽肉分割品 / Poultry carcasses and cuts
Material: SUS304 / 画册标注 Brochure
Voltage: 按目的地和铭牌确认 / Confirm for destination & nameplate
Power: 0.55 kW（画册 / brochure）

Request a quote for this machine ↗

Technical specifications

Source: manufacturer 35-page product brochure, PDF page 31. Reference model: SR-FJ800 Brochure nominal output: 3000 units/h / 件/小时 Brochure power: 0.55 kW Dimensions (L × W × H, mm): 4000 × 600 × 800 4–15 grades. IP67 is stated in the brochure; confirm which components it applies to in the order. Weight range and accuracy in grams are not provided and are not inferred. Selection reference: final configuration, output and acceptance criteria are agreed for each project.
